2. The curved, static Keller–Segel equation

Let $g_0$ be the standard metric on $\mathbb {R}^{2}$, let $\varphi \in C_\mathrm {cpt}^{\infty } ( \mathbb {R}^{2} )$, let $g_\varphi := e^{2 \varphi } g_0$. Let $L_k^{p} ( \mathbb {R}^{2},\, g_\varphi )$ be Banach space of functions on $\mathbb {R}^{2}$ that are $L_k^{p}$ with respect to $g_\varphi$. Note that the properties of being bounded in $L_{1, \mathrm {loc}}^{2}$ are independent of the chosen metric. Finally, let $L_+^{1} ( \mathbb {R}^{2},\, g_\varphi ) \subseteq L^{1} ( \mathbb {R}^{2},\, g_\varphi )$ be the space of almost everywhere positive functions.

The area form and the Laplacian behave under a conformal change via

\[ \: \mathrm{dA}_\varphi = e^{2 \varphi} \: \mathrm{dA}_0 \quad \& \quad \Delta_\varphi = e^{- 2 \varphi} \Delta_0. \]

Thus the Green's function is conformally invariant:

\[ G (x, y) ={-} \frac{1}{2 \pi} \ln \left( |x - y| \right). \]

For any $\varrho \in L_+^{1} ( \mathbb {R}^{2},\, g_\varphi )$, let

\[ c_{\varphi, \varrho} := \int_{\mathbb{R}^{2}} G ({\cdot}, y) \varrho (y) \: \mathrm{dA}_\varphi (y), \]

when the integral exists. Assume that the function $\varrho \in L_+^{1} ( \mathbb {R}^{2},\, g_\varphi ) \cap L_{1, \mathrm {loc}}^{2}$ is such that $c_{\varphi, \varrho }$ is defined on $\mathbb {R}^{2}$. Then $\varrho$ is a solution to the static Keller–Segel equation on $( \mathbb {R}^{2},\, g_\varphi )$ if it solves (the weak version of)

(2.1)\begin{equation} \Delta_\varphi \varrho - \operatorname{d\!}{}^{*} \left( \varrho \operatorname{d\!}{} c_{\varphi, \varrho} \right) = 0. \end{equation}

In the next section we prove that, under mild hypotheses, equation (2.1) is equivalent to the simpler

(2.2)\begin{equation} \operatorname{d\!}{} \left( \ln \left( \varrho \right) - c_{\varphi, \varrho} \right) = 0. \end{equation}

We call equation (2.2) the reduced, static Keller–Segel equation.

In applications it is always assumed that $\varrho$ has finite mass. Furthermore, the minimal regularity needed for the weak version of equation (2.1) is $L_{1, \mathrm {loc}}^{2}$ and the fact that $c_{\varphi, \varrho }$ is defined. Finally, we impose the finiteness of the entropy: $\varrho \ln ( \varrho ) \in L^{1} ( \mathbb {R}^{2},\, g_\varphi )$. This is implied by, for example, the finiteness of the Keller–Segel free energy; cf $\mathbb {S}$ 5.2. With that in mind, we define the (curved) Keller–Segel configuration space as:

(2.3)\begin{equation} \mathcal{C}_\mathrm{KS} (m, \varphi) := \left\{ \ \varrho \in L_+^{1} \left( \mathbb{R}^{2}, g_\varphi \right) \cap L_{1, \mathrm{loc}}^{2} \ \middle| \ \begin{array}{l} \varrho \ln \left( \varrho \right) \in L^{1} \left( \mathbb{R}^{2}, g_\varphi \right), \\ \| \varrho \|_{L^{1} \left( \mathbb{R}^{2}, g_\varphi \right)} = m, \\ c_{\varphi, \varrho} \mbox{ is defined everywhere.} \end{array} \right\}. \end{equation}

Let $r (x) := |x|$ be the euclidean radial function. First we prove a bound on $c_{\varphi, \varrho }$.

Proof. As $\Delta _\varphi c_{\varphi, \varrho } \in L^{1} ( B_1 (0),\, g_\varphi )$, it is enough to prove, without any loss of generality, the boundedness of $c_{\varphi, \varrho } + \tfrac {m}{2 \pi } \ln ( r )$, when $r \geqslant 1$.

Since $c_{\varphi, \varrho } (0) = - \tfrac {1}{2 \pi } \int _{\mathbb {R}^{2}} \varrho \ln (r) \: \mathrm {dA}_\varphi$ is finite, we have that

\begin{align*} c_{\varphi, \varrho} (x) & \leqslant o (1) - \frac{1}{2 \pi} \int_{B_{|x|/2} (x)} \ln \left( |x - y| \right) \varrho (y) \: \mathrm{dA}_\varphi (y) \\ & \leqslant o (1) - \frac{1}{2 \pi} \ln \left( |x| \right) \int_{B_{|x|/2} (x)} \varrho \: \mathrm{dA}_\varphi \\ & \leqslant O (1) - \frac{m}{2 \pi} \ln \left( |x| \right) + \frac{1}{2 \pi} \int_{\mathbb{R}^{2} - B_{|x|/2} (x)} \ln (r) \varrho \: \mathrm{dA}_\varphi \\ & \leqslant O (1) - \frac{m}{2 \pi} \ln \left( |x| \right). \end{align*}

This proves the upper bound.

In order to get the lower bound, let us use Jensen's inequality to get

\begin{align*} c_{\varphi, \varrho} (x) - c_{\varphi, \varrho} (0) & ={-} \frac{m}{2 \pi} \int_{\mathbb{R}^{2}} \ln \left( \frac{|x - y|}{|y|} \right) \frac{\varrho (y) \: \mathrm{dA}_\varphi (y)}{m}\notag\\ & \geqslant - \frac{m}{2 \pi} \ln \left( \ \int_{\mathbb{R}^{2}} \frac{|x - y|}{|y|} \varrho (y) \: \mathrm{dA}_\varphi (y) \right) + \frac{m}{2 \pi} \ln (m). \end{align*}

Since $\varrho \in L_{1, \mathrm {loc}}^{2}$, we get that there exists $\delta > 0$, such that for all $p > 1$, $\varrho \in L^{p} ( B_\delta (0) )$. We can assume that $\delta \leqslant 1$. Since for all $q \in [1,\, 2)$, $r^{- 1} \in L^{q} ( B_\delta (0) )$ and $\tfrac {|x - y|}{|y|} \leqslant \tfrac {\sqrt {|x|^{2} + \delta ^{2}}}{\delta }$ on $\mathbb {R}^{2} - B_\delta (0)$, we get that, for any $p > 1$, that

\begin{align*} & \int_{\mathbb{R}^{2}} \frac{|x - y|}{|y|} \varrho (y) \: \mathrm{dA}_\varphi (y)\\ & \quad = \left( \ \int_{B_\delta (0)} + \int_{\mathbb{R}^{2} - B_\delta (0)} \right) \frac{|x - y|}{|y|} \varrho (y) \: \mathrm{dA}_\varphi (y) \\ & \quad\leqslant \left( e^{2 \| \varphi \|_{L^{\infty} \left( B_\delta (0) \right)}} \| \varrho \|_{L^{p} \left( B_\delta (0) \right)} \| r^{- 1} \|_{L^{\frac{p}{p - 1}} \left( B_\delta (0) \right)} + m \right) \frac{\sqrt{|x|^{2} + \delta^{2}}}{\delta}. \end{align*}

Thus, when $r \geqslant 1$, we get that

\[ c_{\varphi, \varrho} + \frac{m}{2 \pi} \ln \left( r \right) \geqslant C (\varphi, \varrho), \]

which completes the proof.

3. Reduction of order and the necessity of $m = 8 \pi$

Theorem 3.1 Let $\varrho \in \mathcal {C}_\mathrm {KS} (m,\, \varphi )$ be a solution of the static Keller–Segel equation (2.1). Furthermore assume the following bound: there exists a positive number $C,$ such that on $\mathbb {R}^{2} - B_C (0),$ we have

(3.1)\begin{equation} \varrho \leqslant C r^{Cr^{2}}. \end{equation}

Then the reduced, static Keller–Segel equation (2.2) holds, that is $\operatorname {d\!}{} ( \ln ( \varrho ) - c_{\varphi, \varrho } ) = 0$.

Remark 3.3 A corollary of the reduced, static Keller–Segel equation (2.2) is that the (nonreduced) static Keller–Segel equation (2.1) is no longer nonlocal, as $c_{\varrho, \varphi }$ can be eliminated using $\operatorname {d\!}{} c_{\varphi, \varrho } = \operatorname {d\!}{} ( \ln ( \varrho ) ) = \tfrac {\operatorname {d\!}{} \varrho }{\varrho }$, and get

\[ \operatorname{d\!}{}^{*} \left( \varrho \operatorname{d\!}{} c_{\varphi, \varrho} \right) ={-} g_\varphi \left( \operatorname{d\!}{} \varrho, \operatorname{d\!}{} c_{\varphi, \varrho} \right) + \varrho \Delta_\varphi c_{\varphi, \varrho} ={-} g_\varphi \left( \operatorname{d\!}{} \varrho, \tfrac{\operatorname{d\!}{} \varrho}{\varrho} \right) + \varrho^{2} ={-} \frac{|\operatorname{d\!}{} \varrho|_\varphi^{2}}{\varrho} + \varrho^{2}. \]

Thus the static Keller–Segel equation (2.1) becomes

\[ \Delta_\varphi \varrho + \frac{|\operatorname{d\!}{} \varrho|_\varphi^{2}}{\varrho} - \varrho^{2} = 0. \]

Proof of theorem 3.1. Let $f := \ln ( \varrho ) - c_{\varphi, \varrho }$. The static Keller–Segel equation (2.1) implies that

\[ \forall R \in \mathbb{R}_+ : \forall \phi \in L_{1, 0}^{2} \left( B_R (0), g_\varphi \right) : \quad \int_{\mathbb{R}^{2}} \varrho g_0 \left( \operatorname{d\!}{} \phi, \operatorname{d\!}{} f \right) \: \mathrm{dA}_0 = 0. \]

We now apply an Agmon-trick type argument: Let $\chi$ be a smooth and compactly supported function. Then, using $\phi = f \chi ^{2}$ in the second row, we get

\begin{align*} \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} \left( \chi f \right) \right|^{2} \: \mathrm{dA}_0 & = \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} \chi \right|^{2} f^{2} \: \mathrm{dA}_0 + 2 \int_{\mathbb{R}^{2}} \varrho f \chi g_0 \left( \operatorname{d\!}{} \chi, \operatorname{d\!}{} f \right) \: \mathrm{dA}_0\notag\\ & \quad + \int_{\mathbb{R}^{2}} \varrho \chi^{2} \left| \operatorname{d\!}{} f \right|^{2} \: \mathrm{dA}_0 \nonumber\\ & = \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} \chi \right|^{2} f^{2} \: \mathrm{dA}_0 + \int_{\mathbb{R}^{2}} \varrho g_0 \left( \operatorname{d\!}{} \left( f \chi^{2} \right), \varrho \operatorname{d\!}{} f \right) \: \mathrm{dA}_0\notag\\ & \quad - \int_{\mathbb{R}^{2}} \varrho \chi^{2} \left| \operatorname{d\!}{} f \right|^{2} \: \mathrm{dA}_0 + \int_{\mathbb{R}^{2}} \varrho \chi^{2} \left| \operatorname{d\!}{} f \right|^{2} \: \mathrm{dA}_0 \nonumber\\ & = \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} \chi \right|^{2} f^{2} \: \mathrm{dA}_0. \end{align*}

Now for each $R \gg 1$, let $\chi = \chi _R$ be a smooth cut-off function that is 1 on $B_R (0)$, vanishes on $\mathbb {R}^{2} - B_{2 R} (0)$, and (for some $K \in \mathbb {R}_+$) $|\operatorname {d\!}{} \chi _R| = \tfrac {K}{R}$. Let $A_R = B_{2 R} (0) - B_R (0)$. Then we get that

\begin{align*} \int_{\mathbb{R}^{2}} \varrho |\operatorname{d\!}{} f|^{2} \: \mathrm{dA}_0 & \leqslant \liminf\limits_{R \rightarrow \infty} \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} \left( \chi_R f \right) \right|^{2} \: \mathrm{dA}_0\\ & = \liminf\limits_{R \rightarrow \infty} \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} \chi_R \right|^{2} f^{2} \: \mathrm{dA}_0 \leqslant \liminf\limits_{R \rightarrow \infty} \frac{K^{2}}{R^{2}} \int_{A_R} \varrho f^{2} \: \mathrm{dA}_0. \end{align*}

To complete the proof, we show now that the last limit inferior is zero. Since

\[ \int_{A_R} \varrho f^{2} \: \mathrm{dA}_0 \leqslant \left( \sqrt{\int_{A_R} \varrho \ln \left( \varrho \right)^{2} \: \mathrm{dA}_0} + \sqrt{\int_{A_R} \varrho c_{\varphi, \varrho}^{2} \: \mathrm{dA}_0} \right)^{2}, \]

it is enough to show that both terms under the square roots are $o ( R^{2} )$, at least for some divergent sequence of radii. This is immediate for the second term by lemma 2.1. To bound the first term, let $C$ be the constant from equation (3.1) and break up $A_R$ into 2 pieces:

\begin{align*} A_{R, I} & := \left\{ \ x \in A_R \ \middle| \ \varrho (x) \leqslant r (x)^{- C r(x)^{2}} \ \right\}, \\ A_{R, II} & := \left\{ \ x \in A_R \ \middle| \ r (x)^{- C r(x)^{2}} \leqslant \varrho (x) \leqslant r (x)^{C r(x)^{2}} \ \right\}. \end{align*}

By equation (3.1), $A_R = A_{R, I} \cup A_{R, II}$. Let us first inspect

\begin{align*} 0 & \leqslant \int_{A_{R, I}} \varrho \ln \left( \varrho \right)^{2} \: \mathrm{dA}_0\\ & \leqslant C (2 R)^{- C (2 R)^{2}} \ln \left( C (2 R)^{- C (2 R)^{2}} \right)^{2} \mathrm{Area} \left( A_{R, I}, g_0 \right) = o \left( R^{2} \right). \end{align*}

Finally, note that on $A_{R, II}$, we have $\left | \ln ( \varrho ) \right | = O ( R^{2} \ln (R) )$. Thus, for $R \gg 1$, we have

\begin{align*} 0 & \leqslant \int_{A_{R, II}} \varrho \ln \left( \varrho \right)^{2} \: \mathrm{dA}_0\\ & \leqslant \| \ln \left( \varrho \right) \|_{L^{\infty} \left( A_{R, II} \right)} \int_{A_{R, II}} \varrho \left| \ln \left( \varrho \right) \right| \: \mathrm{dA}_0 \leqslant 8 C R^{2} \ln \left( R \right) \int_{A_{R, II}} \varrho \left| \ln \left( \varrho \right) \right| \: \mathrm{dA}_0. \end{align*}

Now let $R_k := 2^{k}$, and then

\[ 0 \leqslant \frac{1}{R_k^{2}} \int_{A_{R_k, II}} \varrho \ln \left( \varrho \right)^{2} \: \mathrm{dA}_0 \leqslant 8 C \ln (2) k \int_{A_{R_k, II}} \varrho \left| \ln \left( \varrho \right) \right| \: \mathrm{dA}_0. \]

Since $\varrho \ln ( \varrho ) \in L^{1} ( \mathbb {R}^{2},\, g_0 )$ we have that

\[ \liminf\limits_{k \rightarrow \infty} \: \left( k \int_{A_{R_k, II}} \varrho \left| \ln \left( \varrho \right) \right| \: \mathrm{dA}_0 \right) = 0, \]

and thus

\[ 0 \leqslant \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} f \right|^{2} \: \mathrm{dA}_0 \leqslant \liminf\limits_{k \rightarrow \infty} \frac{K^{2}}{R_k^{2}} \int_{A_{R_k}} \varrho f^{2} \: \mathrm{dA}_0 = 0, \]

and hence

\[ \int_{\mathbb{R}^{2}} \varrho \left| \operatorname{d\!}{} f \right|^{2} \: \mathrm{dA}_0 = 0, \]

which implies equation (2.2), and thus completes the proof.

Corollary 3.4 If $\varrho \in \mathcal {C}_\mathrm {KS}$ is a solution of the static Keller–Segel equation (2.1) and satisfies (3.1), then there is a number $K = K (\varphi,\, \varrho ) \geqslant 1$ such that

(3.2)\begin{equation} K \geqslant \varrho \left( 1 + r^{2} \right)^{\frac{m}{4 \pi}} \geqslant K^{- 1}. \end{equation}

In particular, $\varrho \sim r^{- \frac {m}{2 \pi }}$ and $m > 4 \pi$.

Proof. We have

\begin{align*} \ln \left( \varrho \left( 1 + r^{2} \right)^{\frac{m}{4 \pi}} \right) & = \ln \left( \varrho \right) + \tfrac{m}{4 \pi} \ln \left( 1 + r^{2} \right)\\ & = \underbrace{\ln \left( \varrho \right) - c_{\varphi, \varrho}}_{\mbox{constant by theorem~3.1}} + \underbrace{c_{\varphi, \varrho} + \tfrac{m}{4 \pi} \ln \left( 1 + r^{2} \right)}_{\mbox{bounded by lemma~2.1}}, \end{align*}

which concludes the proof.

Remark 3.6 Before stating our next theorem, let us recall a few facts, commonly used in literature of the Keller–Segel equations.

First of all, and to the best of our knowledge, the only known solutions in the flat case are the ones given in equation (1.4). Note that they all have mass $8 \pi$.

A complementary fact, supporting the conjecture that static solutions must have mass $8 \pi$, is the the following ‘Virial Theorem’ that applies to the time-dependent equation as well: Assume that $\varrho$ is a solution to the (time-dependent) Keller–Segel equation (1.1a) and (1.1b), such that for all $t$ in the domain of $\varrho$ the following quantity is finite

\[ W (t) := \int_{\mathbb{R}^{2}} |x|^{2} \varrho (t, x) \: \mathrm{dA}_0 (x). \]

Then $W$ satisfies the following equation (cf. [Reference Blanchet, Dolbeault and Perthame2]*lemma 22 for the proof):

\[ \dot{W} (t) = 4\,m - \frac{m}{2 \pi}. \]

In particular, if $\varrho$ is a (positive) solution to the static Keller–Segel equation (2.1) with finite $W$, then $m = 8 \pi$. Note that for each $\varrho _{\lambda, x_\star }$ in equation (1.4), we get $W = \infty$, so the above two results are indeed complementary.

In the next theorem we prove that, under equation (3.1), all (positive) solutions to the static Keller–Segel equation (2.1) must have mass $8 \pi$.

Proof. By corollary 3.4, we have that $m > 4 \pi$ and thus, for some $\epsilon > 0$, we have $\varrho = O ( r^{- 2 - \epsilon } )$.

Let now $v = (v_1,\, v_2)$ be a smooth, compactly supported vector field. Let us pair both sides of equation (2.2) with $- \varrho v$, integrate over $\mathbb {R}^{2}$ with respect to $\: \mathrm {dA}_0$ and then integrate by parts in the first term to get

(3.3)\begin{equation} \sum\limits_{i = 1}^{2} \left( \ \int_{\mathbb{R}^{2}} \varrho \left( \partial_i v_i + v_i \partial_i c_{\varphi, \varrho} \right) \: \mathrm{dA}_0 \ \right) = 0. \end{equation}

For any smooth, real function $f$, let

\[ v^{f} (x) := \left( 2 x_1 e^{2 \varphi (x)} + \partial_1 f, 2 x_2 e^{2 \varphi (x)} + \partial_2 f \right), \]

and let $\chi _R$ as in the proof of theorem 3.1. Let us assume that $\left | \operatorname {d\!}{} f \right | \in L^{2} ( \mathbb {R}^{2},\, g_\varphi )$. Then for $v = \chi _R v^{f}$ equation (3.3) becomes

(3.4)\begin{equation} \begin{aligned} 0 & = \sum\limits_{i = 1}^{2} \left( \ \int_{\mathbb{R}^{2}} \varrho \left( \chi_R \partial_i v_i^{f} + \chi_R \varrho v_i^{f} \partial_i c_{\varphi, \varrho} + \partial_i \chi_R v_i^{f} \right) \: \mathrm{dA}_0 \ \right) \\ & = \sum\limits_{i = 1}^{2} \bigg( \ \int_{\mathbb{R}^{2}} \chi_R (x) \varrho (x) \Big( 2 e^{2 \varphi (x)} + 4 x_i \partial_i \varphi (x) e^{2 \varphi (x)} + \partial_i^{2} f (x)\\ & \quad + \left( 2 x_i e^{2 \varphi (x)} + \partial_i f (x) \right) \partial_i c_{\varphi, \varrho} (x) \Big) \: \mathrm{dA}_0 (x) \ \bigg) \\ & \quad + O \left( \ \int_{B_{2R} (0) - B_R (0)} |\operatorname{d\!}{} \chi_R| \left| v^{f} \right| \varrho \: \mathrm{dA}_\varphi \right) \\ & = 4 \underbrace{\int_{\mathbb{R}^{2}} \chi_R \varrho \: \mathrm{dA}_\varphi}_{\mathcal{I}_1 (R)} + 2 \underbrace{\sum\limits_{i = 1}^{2} \ \int_{\mathbb{R}^{2}} \chi_R (x) \varrho(x) x_i \partial_i c_{\varphi, \varrho} (x) \: \mathrm{dA}_\varphi (x)}_{\mathcal{I}_2 (R)}\\ & \quad + \underbrace{\sum\limits_{i = 1}^{2} \left( \ \int_{\mathbb{R}^{2}} \chi_R \varrho \left( 4 r \partial_r \varphi - \Delta_\varphi f - g_\varphi \left( \operatorname{d\!}{} f, \operatorname{d\!}{} c_{\varphi, \varrho} \right) \right) \: \mathrm{dA}_0 \ \right)}_{\mathcal{I}_3 (R)} \\ & \quad + O \left( R^{- 1} \left( R + \| \operatorname{d\!}{} f \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)} \right) R^{- 2 - \epsilon} R^{2} \right). \end{aligned} \end{equation}

As $R \rightarrow \infty$ the last term goes to zero, by definition, $\mathcal {I}_1 (R) \rightarrow m$. Using equation (2), we get

\begin{align*} \mathcal{I}_2 (R) & = \sum\limits_{i = 1}^{2} \ \int_{\mathbb{R}^{2}} \chi_R (x) x_i \partial_i c_{\varphi, \varrho} (x) \: \mathrm{dA}_\varphi (x) \\ & ={-} \frac{1}{2 \pi} \sum\limits_{i = 1}^{2} \ \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \chi_R (x) \varrho (x) x_i \partial_i \ln \left( |x - y| \right) \varrho (y) \: \mathrm{dA}_\varphi (y) \: \mathrm{dA}_\varphi (x) \\ & ={-} \frac{1}{2 \pi} \sum\limits_{i = 1}^{2} \ \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \chi_R (x) \varrho (x) x_i \frac{x_i - y_i}{|x - y|^{2}} \varrho (y) \: \mathrm{dA}_\varphi (y) \: \mathrm{dA}_\varphi (x), \end{align*}

thus

\begin{align*} \lim\limits_{R \rightarrow \infty} \mathcal{I}_2 (R) & ={-} \frac{1}{2 \pi} \sum\limits_{i = 1}^{2} \ \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) x_i \frac{x_i - y_i}{|x - y|^{2}} \varrho (y) \: \mathrm{dA}_\varphi (y) \: \mathrm{dA}_\varphi (x) \\ & ={-} \frac{1}{2 \pi} \sum\limits_{i = 1}^{2} \ \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) \left( \frac{x_i - y_i}{2} + \frac{x_i + y_i}{2} \right) \frac{x_i - y_i}{|x - y|^{2}} \varrho (y) \: \mathrm{dA}_\varphi (y) \: \mathrm{dA}_\varphi (x) \\ & ={-} \frac{1}{4 \pi} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) \varrho (y) \: \mathrm{dA}_\varphi (y) \: \mathrm{dA}_\varphi (x) + \underbrace{0}_{\mbox{due to antisymmetry}} \\ & ={-} \frac{m^{2}}{4 \pi}. \end{align*}

Finally, if we can choose a smooth $f$ so that

(3.5)\begin{equation} \Delta_\varphi f + g_\varphi \left( \operatorname{d\!}{} f, \operatorname{d\!}{} c_{\varphi, \varrho} \right) = 4 r \partial_r \varphi, \end{equation}

and $|\operatorname {d\!}{} f| \in L^{2} ( \mathbb {R}^{2},\, g_\varphi )$, then $\mathcal {I}_3 (R) = 0$, for all $R$. For any smooth, compactly supported function $\phi$, let

\[ \| \phi \|_{\varphi, \varrho} := \sqrt{ \| \operatorname{d\!}{} \phi \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)}^{2} + \tfrac{1}{2} \| \sqrt{\varrho} \phi \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)}^{2}}, \]

and let $( \mathcal {H}_{\varphi, \varrho },\, \langle - | - \rangle _{\varphi, \varrho } )$ the corresponding Hilbert space. Clearly $\mathcal {H}_{\varphi, \varrho } \subseteq L_{1, \mathrm {loc}}^{2}$. The weak formulation of equation (3.5) on $\mathcal {H}_{\varphi, \varrho }$ is

\[ \forall \phi \in C_{\mathrm{cpt}}^{\infty} \left( \mathbb{R}^{2} \right) : \quad \underbrace{\langle \operatorname{d\!}{} \phi | \operatorname{d\!}{} f \rangle_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)} + \int_{\mathbb{R}^{2}} \phi g_\varphi \left( \operatorname{d\!}{} f, \operatorname{d\!}{} c_{\varphi, \varrho} \right) \: \mathrm{dA}_\varphi}_{B \left( f, \phi \right)} = \underbrace{\int_{\mathbb{R}^{2}} \phi r \partial_r \varphi \: \mathrm{dA}_\varphi}_{\Phi_\varphi \left( \phi \right)}. \]

Now if $f = \phi \in C_{\mathrm {cpt}}^{\infty } ( \mathbb {R}^{2} )$, then

\begin{align*} B \left( \phi, \phi \right) & = \langle \operatorname{d\!}{} \phi | \operatorname{d\!}{} \phi \rangle_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)} + \int_{\mathbb{R}^{2}} \phi g_\varphi \left( \operatorname{d\!}{} \phi, \operatorname{d\!}{} c_{\varphi, \varrho} \right) \: \mathrm{dA}_\varphi \\ & = \| \operatorname{d\!}{} \phi \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)}^{2} + \frac{1}{2} \int_{\mathbb{R}^{2}} g_\varphi \left( \operatorname{d\!}{} \phi^{2}, \operatorname{d\!}{} c_{\varphi, \varrho} \right) \: \mathrm{dA}_\varphi \\ & = \| \operatorname{d\!}{} \phi \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)}^{2} + \frac{1}{2} \int_{\mathbb{R}^{2}} \phi^{2} \Delta_\varphi c_{\varphi, \varrho} \: \mathrm{dA}_\varphi \\ & = \| \operatorname{d\!}{} \phi \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)}^{2} + \frac{1}{2} \int_{\mathbb{R}^{2}} \phi^{2} \varrho \: \mathrm{dA}_\varphi \\ & = \| \phi \|_{\varphi, \varrho}^{2}, \end{align*}

and, using that $\varphi$ has compact support and equation (3.2), we have

\begin{align*} \left| \Phi_\varphi \left( \phi \right) \right| & = \int_{\mathbb{R}^{2}} \phi r \partial_r \varphi \: \mathrm{dA}_\varphi \\ & = \int_{\mathbb{R}^{2}} \left( \phi \sqrt{\varrho} \right) \left( \frac{r \partial_r \varphi}{\sqrt{\varrho}} \right) \: \mathrm{dA}_\varphi \\ & \leqslant \| \phi \sqrt{\varrho} \|_{L^{2} \left( \mathbb{R}^{2}, g_\varphi \right)} \sqrt{\int_{\mathbb{R}^{2}} \tfrac{r^{2} \left( \partial_r \varphi \right)^{2}}{\varrho} \: \mathrm{dA}_\varphi} \\ & \leqslant K (\varphi, \varrho) \| \phi \|_{\varphi, \varrho}. \end{align*}

Thus the conditions of the Lax–Milgram theorem are satisfied and hence there is a unique $f \in \mathcal {H}_{\varphi, \varrho }$ that solves equation (3.5). By elliptic regularity, $f$ is in fact smooth and by the definition $\mathcal {H}_{\varphi, \varrho }$, $|\operatorname {d\!}{} f| \in L^{2} ( \mathbb {R}^{2},\, g_\varphi )$. Hence equation (3.4) becomes $0 = 4\,m - \tfrac {m^{2}}{2 \pi }$, which concludes the proof.

4. Connection to the critical Kazdan–Warner equation on the round sphere

Let us assume that $\varrho \in \mathcal {C}_\mathrm {KS}$ is a solution of the static Keller–Segel equation (2.1) and satisfies equation (3.1), and thus $m = 8 \pi$. Fix $\lambda \in \mathbb {R}_+$ and $x_\star \in \mathbb {R}^{2}$, and let $\varrho _{\lambda, x_\star }$ as in equation (1.4). Pick the unique stereographic projection $p_{\lambda, x_\star } : \mathbb {S}^{2} - \{ \mbox { North pole } \} \rightarrow \mathbb {R}^{2}$, so that $g_{\mathbb {S}^{2}} := ( p_{\lambda, x_\star } )^{*} ( \tfrac {1}{2} \varrho _{\lambda, x_\star } g_0 )$ is the round metric of unit radius. By corollary 3.4, the function $\widetilde {u} := \tfrac {1}{2} \ln ( \tfrac {\varrho }{\varrho _{\lambda, x_\star }} )$ is bounded on $\mathbb {R}^{2}$. Let $u := \widetilde {u} \circ p_{\lambda, x_\star } \in L^{\infty } ( \mathbb {S}^{2} )$. Then (omitting obvious pullbacks and computations) we have

\begin{align*} \Delta_{\mathbb{S}^{2}} u & = \frac{1}{\tfrac{1}{2} \varrho_{\lambda, x_\star}} \Delta_0 \left( \frac{1}{2} \ln \left( \frac{\varrho}{\varrho_{\lambda, x_\star}} \right) \right) \\ & = \frac{1}{\varrho_{\lambda, x_\star}} \Delta_0 \left( \left( \ln \left( \varrho \right) - c_{\varphi, \varrho} \right) + c_{\varphi, \varrho} + \ln \left( \varrho_{\lambda, x_\star} \right) \right) \\ & = \frac{1}{\varrho_{\lambda, x_\star}} \left( 0 + e^{2 \varphi} \varrho - \varrho_{\lambda, x_\star} \right) \\ & = e^{2 \varphi} e^{2 u} - 1. \end{align*}

Since $\varphi$ is compactly supported, the pullback of $e^{2 \varphi }$ to $\mathbb {S}^{2}$ via $p_{\lambda, x_\star }$ extends smoothly over the North pole. Let us denote this extension by $h$. Then the equation on $u$ becomes

(4.1)\begin{equation} \Delta_{\mathbb{S}^{2}} u = h e^{2 u} - 1. \end{equation}

This is the equation of Kazdan and Warner, [Reference Kazdan and Warner7]*equation (1.3), with $k = 1$ (note that they use the opposite sign convention for the Laplacian). When $\varphi$ vanishes identically, then $u = 0$ is a solution, which corresponds to the well-known $\varrho = \varrho _{\lambda, x_\star }$ solution on the flat plane. More generally, given any $\lambda \in \mathbb {R}_+$ and $x_\star \in \mathbb {R}^{2}$ and any positive scalar curvature metric $g$ on $\mathbb {S}^{2}$, one can construct a solution to curved, static Keller–Segel equation (2.1) as follows: by the uniformization theorem, $g$ and $g_{\mathbb {S}^{2}}$ are always conformally equivalent. Thus we have a function, $u$, that solves equation (4.1) with $h$ being the scalar curvature of $g$ (pulled back under a diffeomorphism). Let now $\widetilde {u}$ and $\widetilde {h}$ be the pushforwards of $u$ and $h$, respectively, to $\mathbb {R}^{2}$ via $p_{\lambda, x_\star }$, and let $\varrho := \varrho _{\lambda, x_\star } e^{2 \widetilde {u}}$. Then $\varrho$ solves the curved, static Keller–Segel equation (2.1) with $\varphi = \tfrac {1}{2} \ln ( \widetilde {h} )$.

Unfortunately, equation (4.1) is the critical version of the Kazdan–Warner equation in [Reference Kazdan and Warner7]. Thus we cannot, in general, assume solvability for an arbitrary $h$. In fact, Kazdan and Warner found a necessary condition for the existence of solutions: For each spherical harmonic of degree one, $u_1$, by [Reference Kazdan and Warner7]*equation (8.10), we have

(4.2)\begin{equation} \int_{\mathbb{S}^{2}} g_{\mathbb{S}^{2}} \left( \operatorname{d\!}{} u_1, \operatorname{d\!}{} h \right) e^{2 u} \omega_{\mathbb{S}^{2}} = 0, \end{equation}

where $\omega _{\mathbb {S}^{2}}$ is the symplectic/area form of $g_{\mathbb {S}^{2}}$. We use equation (4.2) to prove the following:

Proof. Let us assume that $\varphi$ is radial (with respect to $x_\star$). Then $h$ is only a function of the polar angle $\theta \in ( - \tfrac {\pi }{2},\, \tfrac {\pi }{2} )$, on $\mathbb {S}^{2}$. When $u_1 = \sin ( \theta )$, then equation (4.2) becomes

(4.3)\begin{equation} \int_{\mathbb{S}^{2}} \cos \left( \theta \right) \left( \partial_\theta h \right) e^{2 u} \omega_{\mathbb{S}^{2}} = 0. \end{equation}

Since $\partial _\theta h \sim e^{2 \varphi } \partial _r \varphi$, we get that if $\varphi$ is nonconstant and $\partial _r \varphi$ is either nonnegative or nonpositive, then equation (4.3) cannot hold. This concludes the proof.

5. The variation aspects of the Keller–Segel theory on curved planes

We end this paper with a complementary result to theorem 3.7, showing that the energy functional (formally) corresponding to the Keller–Segel flow in equation (1.1a) and (1.1b) is bounded from below only when $m = 8 \pi$. In order to do that, we first prove a curved version of the logarithmic Hardy–Littlewood–Sobolev inequality.

5.1 Curved logarithmic Hardy–Littlewood–Sobolev inequality and the Keller–Segel free energy

Let $\lambda \in \mathbb {R}_+$ and $x_\star \in \mathbb {R}^{2}$, and define

(5.1)\begin{equation} \mu_{\lambda, x_\star} (x) := \frac{\lambda^{2}}{\pi \left( \lambda^{2} + |x - x_\star|^{2} \right)^{2}}. \end{equation}

Then $\mu _{\lambda, x_\star }$ is everywhere positive, $\int _{\mathbb {R}^{2}} \mu _{\lambda, x_\star } \: \mathrm {dA}_0 = 1$, and for any $f \in C_{\mathrm {cpt}}^{\infty } ( \mathbb {R}^{2} )$

(5.2)\begin{equation} \lim\limits_{\lambda \rightarrow 0} \ \int_{\mathbb{R}^{2}} \mu_{\lambda, x_\star} f \: \mathrm{dA}_0 = f (x_\star). \end{equation}

The following identities about $\mu _{\lambda, x_\star }$ are easy to verify:

(5.3a)\begin{align} \int_{\mathbb{R}^{2}} m \mu_{\lambda, x_\star} \ln \left( m \mu_{\lambda, x_\star} \right) \: \mathrm{dA}_0 & = m \ln \left( \frac{m}{\pi e} \right) - 2\,m \ln (\lambda), \end{align}

(5.3b)\begin{align} \int_{\mathbb{R}^{2}} G ({\cdot}, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_0 (y) & = \frac{1}{8 \pi} \left( \ln \left( \mu_{\lambda, x_\star} \right) - 2 \ln (\lambda) + \ln (\pi) \right), \end{align}

(5.3c)\begin{align} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \mu_{\lambda, x_\star} (x) G (x, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y) & ={-} \frac{1}{2 \pi} \ln (\lambda) - \frac{1}{4 \pi}. \end{align}

Now we can state the logarithmic Hardy–Littlewood–Sobolev inequality on $( \mathbb {R}^{2},\, g_0 )$, which is a special case of [Reference Beckner1]*theorem 2.

Theorem 5.1 Let $\varrho$ be an almost everywhere positive function on $\mathbb {R}^{2}$ and assume that

\[ \int_{\mathbb{R}^{2}} \varrho \: \mathrm{dA}_0 = m \in \mathbb{R}_+. \]

Then for all $\lambda \in \mathbb {R}_+,$ $x_\star \in \mathbb {R}^{2},$ we have

(5.4)\begin{align} & \int_{\mathbb{R}^{2}} \varrho (x) \ln \left( \frac{\varrho (x)}{m \mu_{\lambda, x_\star} (x)} \right) \: \mathrm{dA}_0\notag\\ & \quad \geqslant \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} (\varrho (x) - m \mu_{\lambda, x_\star} (x)) G (x, y) (\varrho (y) - m \mu_{\lambda, x_\star} (y)) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y). \end{align}

Moreover, equality holds exactly when $\varrho = m \mu _{\lambda, x_\star }$.

Idea of the proof: Note that equations (5.3a), (5.3c), and (5.3a) imply that equation (5.4) is equivalent to

(5.5)\begin{align} & \int_{\mathbb{R}^{2}} \varrho (x) \ln \left( \varrho (x) \right) \: \mathrm{dA}_0 + \frac{2}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) \ln \left( |x - y| \right) \varrho (y) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y)\notag\\ & \quad + m \left( 1 + \ln (\pi) - \ln (m) \right) \geqslant 0. \end{align}

Now equation (5.5) is the $n = 2$ and $f = g$ case of [Reference Beckner1]*inequality (27).

Let now $g$ be any smooth Riemannian metric on $\mathbb {R}^{2}$, not necessarily conformally equivalent to $g_0$. There still exists a smooth function, $\varphi$, such that if the area form of $g$ is $\: \mathrm {dA}_g$, then

(5.6)\begin{equation} \: \mathrm{dA}_g = e^{2 \varphi} \: \mathrm{dA}_0. \end{equation}

For the remainder of this section (but this section only), let $\varphi$ be defined via equation (5.6), and write, as before $\: \mathrm {dA}_\varphi := \: \mathrm {dA}_g$. When $g$ is not conformally equivalent to $g_0$, then $G$ is no longer the Green's function for $g$. Now let $\mu _{\lambda, x_\star }^{\varphi } := \mu _{\lambda, x_\star } e^{- 2 \varphi }$. Note that $\int _{\mathbb {R}^{2}} \mu _{\lambda, x_\star }^{\varphi } \: \mathrm {dA}_\varphi = 1$.

The next lemma is a generalization of theorem 5.1.

Lemma 5.2 Let $\varrho$ be an almost everywhere positive function on $\mathbb {R}^{2}$ and assume that

\[ \int_{\mathbb{R}^{2}} \varrho \: \mathrm{dA}_\varphi = m \in \mathbb{R}_+. \]

Then for all $\lambda \in \mathbb {R}_+$ and $x_\star \in \mathbb {R}^{2},$ we have

(5.7)\begin{align} \int_{\mathbb{R}^{2}} \varrho \ln \left( \frac{\varrho}{m \mu_{\lambda, x_\star}^{\varphi}} \right) \: \mathrm{dA}_\varphi & \geqslant \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) - m \mu_{\lambda, x_\star}^{\varphi} (x) \right) G (x, y)\notag\\ & \quad\times \left( \varrho (y) - m \mu_{\lambda, x_\star}^{\varphi} (y) \right) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y), \end{align}

and equality holds exactly when $\varrho = m \mu _{\lambda, x_\star }^{\varphi }$.

Proof. Let us first rewrite the left-hand side of equation (5.7):

(5.8)\begin{align} \int_{\mathbb{R}^{2}} \varrho \ln \left( \frac{\varrho}{m \mu_{\lambda, x_\star}^{\varphi}} \right) \: \mathrm{dA}_\varphi & = \int_{\mathbb{R}^{2}} \varrho \ln \left( \frac{\varrho}{m \mu e^{- 2 \varphi}} \right) e^{2 \varphi} \: \mathrm{dA}_0\notag\\ & = \int_{\mathbb{R}^{2}} \left( \varrho e^{2 \varphi} \right) \ln \left( \frac{\left( \varrho e^{2 \varphi} \right)}{m \mu} \right) \: \mathrm{dA}_0. \end{align}

Since $\varrho e^{2 \varphi }$ is almost everywhere positive and

\[ \int_{\mathbb{R}^{2}} \left( \varrho e^{2 \varphi} \right) \: \mathrm{dA}_0 = \int_{\mathbb{R}^{2}} \varrho \: \mathrm{dA}_\varphi = m, \]

we can use equation (5.4), with $\varrho$ replaced by $\varrho e^{2 \varphi }$, and get

(5.9)\begin{align} \int_{\mathbb{R}^{2}} \left( \varrho e^{2 \varphi} \right) \ln \left( \frac{\left( \varrho e^{2 \varphi} \right)}{m \mu} \right) \: \mathrm{dA}_0 & \geqslant \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) e^{2 \varphi (x)} - m \mu (x) \right) G (x, y) \notag\\ & \quad \times \left( \varrho (y) e^{2 \varphi (y)} - m \mu (y) \right) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y). \end{align}

Furthermore

(5.10)\begin{align} & \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) e^{2 \varphi (x)} - m \mu (x) \right) G (x, y) \left( \varrho (y) e^{2 \varphi (y)} - m \mu (y) \right) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y) \nonumber\\ & \quad= \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) - m \mu (x) e^{- 2 \varphi (x)} \right) G (x, y) \left( \varrho (y) - m \mu (y) e^{- 2 \varphi (y)} \right)\notag\\ & \quad\times \left( e^{2 \varphi (x)} \: \mathrm{dA}_0 (x) \right) \left( e^{2 \varphi (y)} \: \mathrm{dA}_0 (y) \right) \nonumber\\ & \quad= \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) - m \mu_{\lambda, x_\star}^{\varphi} (x) \right) G (x, y) \left( \varrho (y) - m \mu_{\lambda, x_\star}^{\varphi} (y) \right) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y). \end{align}

Combining equations (5.8), (5.9), and (5.10) proves equation (5.7). Finally, equality in equation (5.9) holds exactly when $\varrho e^{2 \varphi } = m \mu$, or equivalently, when $\varrho = m \mu _{\lambda, x_\star }^{\varphi }$, which conclude the proof.

Remark 5.3 As opposed to the flat case, when $\varphi$ is not identically zero, the $m = 8 \pi$ minimizer for the curved logarithmic Hardy–Littlewood–Sobolev equation (5.7), $8 \pi \mu _{\lambda, x_\star }^{\varphi }$, is not a solution to the static Keller–Segel equation (2.1), nor the reduced, static Keller–Segel equation (2.2). Instead, we get

\[ \operatorname{d\!}{} \left( \ln \left( 8 \pi \mu_{\lambda, x_\star}^{\varphi} \right) - c_{\varphi, 8 \pi \mu_{\lambda, x_\star}^{\varphi}} \right) = \operatorname{d\!}{} \left( \ln \left( 8 \pi \mu_{\lambda, x_\star} \right) - 2 \varphi - c_{0, 8 \pi \mu_{\lambda, x_\star}} \right) ={-} 2 \operatorname{d\!}{} \varphi \not \equiv 0. \]

5.2 The Keller–Segel free energy

The (flat) Keller–Segel free energy of $\varrho \in \mathcal {C}_\mathrm {KS} (m,\, 0)$ is

(5.11)\begin{equation} \mathcal{F}_0 \left( \varrho \right) = \int_{\mathbb{R}^{2}} \varrho \ln \left( \varrho \right) \: \mathrm{dA}_0 - \frac{1}{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) G (x, y) \varrho (y) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y). \end{equation}

Remark 5.4 Formally, equation (1.1a) is the negative gradient flow of the Keller–Segel free energy under the Wasserstein metric. Formally this metric can be introduced as follows: If $\varrho \in \mathcal {C}_\mathrm {KS} (m,\, \varphi )$, then the operator $f \mapsto L_\varrho (f) := \operatorname {d\!}{}^{*} ( \varrho \operatorname {d\!}{} f )$ is expected to be nondegenerate. Then if $\dot {\varrho }$ is a tangent vector to $\mathcal {C}_\mathrm {KS} (m,\, \varphi )$, then its Wasserstein norm is given by

\[ \| \dot{\varrho} \|_W^{2} := \int_{\mathbb{R}^{2}} \dot{\varrho} L_\varrho^{- 1} \left( \dot{\varrho} \right) \: \mathrm{dA}_0. \]

Then the Wasserstein norm is a Hilbert norm, thus can be used to define gradient flows.

Remark 5.5 The functional in (5.11) is also the energy of self-gravitating Brownian dust; cf. [Reference Chavanis, Ribot, Rosier and Sire4].

Let us generalize $\mathcal {F}_0$ to $( \mathbb {R}^{2},\, g_\varphi )$: For any $\varrho \in \mathcal {C}_\mathrm {KS} (m,\, \varphi )$, let the curved Keller–Segel free energy be

(5.12)\begin{equation} \mathcal{F}_\varphi \left( \varrho \right) := \int_{\mathbb{R}^{2}} \varrho \ln \left( \varrho \right) \: \mathrm{dA}_\varphi - \frac{1}{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) G (x, y) \varrho (y) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y). \end{equation}

Now we are ready to prove our last main result.

Theorem 5.6 The curved Keller–Segel free energy (5.12) is bounded from below on $\mathcal {C}_\mathrm {KS} (m,\, \varphi ),$ exactly when $m = 8 \pi$.

Proof. Let $m,\, \lambda \in \mathbb {R}_+$, and $\mu _{\lambda, 0}$ as in equation (5.1) (with $x_\star = 0$). Now equations (5.3c) and (5.3a) imply that

\begin{align*} \mathcal{F}_\varphi \left( m \mu_{\lambda, x_\star} e^{- 2 \varphi} \right) & = \int_{\mathbb{R}^{2}} m \mu_{\lambda, x_\star} e^{- 2 \varphi} \ln \left( m \mu_{\lambda, x_\star} e^{- 2 \varphi} \right) \: \mathrm{dA}_\varphi \\ & \quad - \frac{1}{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} m \mu_{\lambda, x_\star} (x) e^{- 2 \varphi (x)}\\ & \quad \times G (x, y) m \mu_{\lambda, x_\star} (y) e^{- 2 \varphi (y)} \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \\ & = \int_{\mathbb{R}^{2}} m \mu_{\lambda, x_\star} \ln \left( m \mu_{\lambda, x_\star} \right) \: \mathrm{dA}_0 - 2\,m \int_{\mathbb{R}^{2}} \mu_{\lambda, x_\star} \varphi \: \mathrm{dA}_0 \\ & \quad - \frac{m^{2}}{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \mu_{\lambda, x_\star} (x) G (x, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y) \\ & = \frac{m}{4 \pi} \left( m - 8 \pi \right) \ln (\lambda) + m \ln \left( \frac{m}{\pi e} \right) - 2\,m \int_{\mathbb{R}^{2}} \mu_{\lambda, x_\star} \varphi \: \mathrm{dA}_0. \end{align*}

As $\lambda \rightarrow 0^{+}$, the last term goes to $\varphi (x_\star )$. Thus, when $m > 8 \pi$, then

\[ \lim\limits_{\lambda \rightarrow 0^{+}} \mathcal{F}_\varphi \left( m \mu_{\lambda, x_\star} e^{- 2 \varphi} \right) ={-} \infty. \]

Similarly, as $\lambda \rightarrow \infty$, the last term goes to zero. Thus, when $m < 8 \pi$, then

\[ \lim\limits_{\lambda \rightarrow \infty} \mathcal{F}_\varphi \left( m \mu_{\lambda, x_\star} e^{- 2 \varphi} \right) ={-} \infty. \]

This proves the claim for $m \neq 8 \pi$.

When $m = 8 \pi$, then for any $\varrho \in \mathcal {C}_\mathrm {KS} (m,\, \varphi )$, we have

\begin{align*} \mathcal{F}_\varphi \left( \varrho \right) & = \int_{\mathbb{R}^{2}} \varrho \ln \left( \varrho \right) \: \mathrm{dA}_\varphi - \frac{1}{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) G (x, y) \varrho (y) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \\ & = \int_{\mathbb{R}^{2}} \varrho \ln \left( \varrho \right) \: \mathrm{dA}_\varphi - \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) G (x, y) \varrho (y) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \\ & = \int_{\mathbb{R}^{2}} \varrho \ln \left( \frac{\varrho}{m \mu_{\lambda, x_\star}^{\varphi}} \right) \: \mathrm{dA}_\varphi - \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) - m \mu_{\lambda, x_\star}^{\varphi} (x) \right)\\ & \quad\times G (x, y) \left( \varrho (y) - m \mu_{\lambda, x_\star}^{\varphi} (y) \right) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \\ & \quad + m \ln (m) - 2 \int_{\mathbb{R}^{2}} \varrho \varphi \: \mathrm{dA}_\varphi + \int_{\mathbb{R}^{2}} \varrho \ln \left( \mu_{\lambda, x_\star} \right) \: \mathrm{dA}_\varphi\\ & \quad - 8 \pi \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) G (x, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_0 (y) \\ & \quad + 4 \pi m^{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \mu_{\lambda, x_\star} (x) G (x, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y) \\ & = \int_{\mathbb{R}^{2}} \varrho \ln \left( \frac\varrho{m \mu_{\lambda, x_\star}^{\varphi}} \right) \: \mathrm{dA}_\varphi - \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) - m \mu_{\lambda, x_\star}^{\varphi} (x) \right)\\ & \quad\times G (x, y) \left( \varrho (y) - m \mu_{\lambda, x_\star}^{\varphi} (y) \right) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \\ & \quad + m \ln (m) - 2 \int_{\mathbb{R}^{2}} \varrho \varphi \: \mathrm{dA}_\varphi\\ & \quad + \int_{\mathbb{R}^{2}} \varrho (x) \left( \ln \left( \mu_{\lambda, x_\star} (x) \right) - 8 \pi \int_{\mathbb{R}^{2}} G (x, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_0 (y) \right) \: \mathrm{dA}_\varphi (x) \\ & \quad + 4 \pi m \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \mu_{\lambda, x_\star} (x) G (x, y) \mu_{\lambda, x_\star} (y) \: \mathrm{dA}_0 (x) \: \mathrm{dA}_0 (y). \end{align*}

Now, using equations (5.7), (5.3b), (5.3c), and (5.2), and plugging back $m = 8 \pi$, we get

\[ \inf \: \left( \left\{ \ \mathcal{F}_\varphi \left( \varrho \right) \ \middle| \ \varrho \in \mathcal{C}_\mathrm{KS} (m, \varphi) \ \right\} \right) = 8 \pi \ln \left( \tfrac{8}{e} \right) - 16 \pi \sup \left( \left\{ \varphi (x) \middle| x \in \mathbb{R}^{2} \right\} \right), \]

which completes the proof.

Remark 5.7 It is not entirely obvious if the relevant generalization of Keller–Segel free energy (5.11) is the functional, $\mathcal {F}_\varphi$, in equation (5.12). There is an generalization that is minimally coupled to the metric: Let $\kappa _\varphi := \Delta _\varphi \varphi$ be the Gauss curvature of $g_\varphi$ and $q \in \mathbb {R}$ be a coupling constant. Then let us define

\begin{align*} \mathcal{F}_{\varphi, q} \left( \varrho \right) & := \int_{\mathbb{R}^{2}} \varrho \ln \left( \varrho \right) \: \mathrm{dA}_\varphi - \frac{1}{2} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \varrho (x) G (x, y) \varrho (y) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \nonumber\\ & \quad + q \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \kappa_\varphi (x) G (x, y) \varrho (y) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y). \end{align*}

When $m \neq 8 \pi$, the proof of theorem 5.6 can still be used to prove the unboundedness of $\mathcal {F}_{\varphi, q}$, and when $m = 8 \pi$, we get

\begin{align*} \mathcal{F}_{\varphi, q} \left( \varrho \right) & \geqslant \int_{\mathbb{R}^{2}} \varrho \ln \left( \frac\varrho{m \mu_{\lambda, x_\star}^{\varphi}} \right) \: \mathrm{dA}_\varphi - \frac{4 \pi}{m} \iint\limits_{\mathbb{R}^{2} \times \mathbb{R}^{2}} \left( \varrho (x) - m \mu_{\lambda, x_\star}^{\varphi} (x) \right)\\ & \quad\times G (x, y) \left( \varrho (y) - m \mu_{\lambda, x_\star}^{\varphi} (y) \right) \: \mathrm{dA}_\varphi (x) \: \mathrm{dA}_\varphi (y) \\ & \quad + (q - 2) \int_{\mathbb{R}^{2}} \varrho \varphi \: \mathrm{dA}_\varphi \: \mathrm{dA}_\varphi + 8 \pi \ln \left( \tfrac{8}{e} \right). \end{align*}

In particular, when $q = 2$, then $\varrho = 8 \pi \mu _{\lambda, x_\star }^{\varphi }$ is an absolute minimizer of $\mathcal {F}_{\varphi, q}$.
